Horizontal Multistage Pumps
- SM80
- SM100
- SM125
- SM150
- SM200
- SM300
Product Specification
For Pumping water in Residences, RO Plant, HVAC, Industrial & Residential Pressure boosting system.
| Pump Body | Stainless Steel |
| Shaft | AISI30 |
| Diffuser | Techno-polymer |
| Protection | IP55 |
| Impeller | SS/Techno-Polymer |
| Motor Winding | Copper |
| Mechanical Seal | Carbon/Ceramic |
| Max Suction | 9 Meter |
| Technical Features | SM80 | SM100 | SM125 | SM150 | SM200 | SM300 |
|---|---|---|---|---|---|---|
| Power | 0.8 HP / 0.55 kW | 1 HP / 0.75 kW | 1.25 HP / 0.9 kW | 1.5 HP / 1.1 kW | 2.2 HP / 1.65 kW | 3 HP / 2.2 kW |
| Rated Voltage | 220 V | 220 V | 220 V | 220 V | 220 V | 220 V |
| Frequency | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz |
| Max Operating Temp. | 50° c | 50° c | 50° c | 50° c | 50° c | 50° c |
| Max Head | 30 Meter | 40 Meter | 40 Meter | 65 Meter | 60 Meter | 70 Meter |
| Max Discharge | 60 l/min | 70 l/min | 120 l/min | 150 l/min | 180 l/min | 210 l/min |
| Inlet / Outlet | 1”x1” | 1”x1” | 1”x1” | 1”x1” | 1.25”x1.25” | 1.25”x1.25” |
