High Head Pump
- SCW100H
- SCW150H
Product Specification
High head pumps to pump water from ponds in construction site.
| Motor Housing | Stainless Steel |
| Impeller | Cast Iron |
| Protection | IP68 |
| Insulation | Class B |
| Motor Winding | Copper |
| Pump Body | Cast Iron |
| Shaft: | AISI304 SS |
| Seal: | Double Mechanical Seal |
| Supplied with 10 meters cable & float switch | |
| Technical Features | SCW100H | SCW150H |
|---|---|---|
| Power | 1.1 kW / 1.5 HP | 1.5 kW / 2 HP |
| Voltage | 220 V – 240 V | 220 V – 240 V |
| Frequency | 50 Hz | 50 Hz |
| RPM | 2850 | 2850 |
| Max Head | 28 Meter | 42 Meter |
| Max Discharge | 250 l/min | 300 l/min |
| Max Solid Passage | 0.2 mm | 0.2 mm |
| Outlet | 2” | 2” |
